Ebara DLFU / D-U Repair Kit

buy ebara pump repair kit
Additional images
ebara d series 25 mm
buy ebara pump repair kit
ebara d series 40 MM
ebara d series 45mm

Ebara DLFU / D-U Repair Kit

SKU: N/A

Weight 3 lbs
Dimensions 10 × 8 × 4 in
QTY Price
Have a Question?
  • DESCRIPTION

    Ebara DLFU / D-U Seal Kit — Select by Rated kW

    Order the correct Ebara DLFU / D-U mechanical seal kit for your Ebara D-Series submersible pump by selecting your pump’s rated kW (HP shown for reference). Each kW range corresponds to a specific seal size/build, and some kits include the remembered “full rebuild” contents (dual seals + O-rings + lip seal + fiber washers).

    ***Important Note: Please click “physical properties” tab below for information on how to read Ebara D-Series model numbers (for seal sizing) or click our Ebara Repair Kit Seal Guide

    Choose your kW rating in the dropdown menu above to view the exact seal photo for your pump.

    1.5 kW (= 2 HP)

    • Build: 25 mm mechanical seal only

    • O-ring kit: Not available for this size

    2.2–3.7 kW (= 3–5 HP)

    • Build: 30 mm mechanical seal

    • O-ring kit: Available (model-specific)

    • Typical compatibility examples:

      • Ebara: DL / ZDLX (DL) / DLF / DLFU / DLMFMU (up to 5 HP)

      • HCP: 50GF24.5, 50GF23.7 (3.7 kW = 5 HP)

      • Other refs seen: MTS/M…, F21-0B030NS0000-0, 80DLMKFU, 80DLMFMU (3 HP)

    5.5 / 7.5 / 11 kW (= 7.5 / 10 / 15 HP)

    • Build: 40 mm seal set

    • Kit includes:

      • Both mechanical seals (ADLFM 040)

      • O-rings (ORDLFU 7.5-10-15)

      • Lip seal and small fiber washers

    • Note: If your model has a water jacket (e.g., DDLFU, “DD” = water jacket), mention this at checkout.

    15 / 18 / 22 kW (= 20 / 25 / 30 HP)

    • Build: 45 mm seal set

    • Kit includes:

      • Both mechanical seals (ADLFM 045)

      • O-rings (ORDLFU 20-25-30)

      • Lip seal and small fiber washers

    • Note: Water-jacket models (e.g., DDLFU)—please indicate when ordering.

    30 / 37 kW (= 40 / 50 HP)

    • Build: 45 mm seal set

    • Kit includes:

      • Both mechanical seals (ADLFM 045)

      • O-rings (ORDLFU 40-50)

      • Lip seal and small fiber washers

    Special order: For 45 kW (= 60 HP) applications, please call to order.

    Fitment & Cross-Reference

    • Full OEM cross-reference details are listed in the Specifications tab.

    • To ensure an exact match, provide your full nameplate string (e.g., 150DLFU6304) and note any water-jacket designation (DD) during checkout process under tab “Pump Model Number Notes”

    Not sure which kit you need? Contact us—we’ll confirm by model and duty.

    Have questions? Check out our Ebara Repair Kit Seal Guide or call us anytime- we’re here to help

    Explore our full line up of Pump Repair Kits

    Looking for more? Check out our Shaft seals, Parts/Accessories & OEM seals

  • SPECIFICATIONS
    Cross References / Alternative Part Numbers

    Kit naming (common search variations)

    • Ebara DLFU / D-U Kit

    • Ebara D-Series Seal Kit

    • DLFU Seal Kit, D-U Seal Kit, DLFU repair kit

    Seal set / kit codes often referenced

    • ADLFM 040 (40mm seal set kits)

    • ADLFM 045 (45mm seal set kits)

    • ORDLFU 7.5-10-15 (O-ring kit for 5.5/7.5/11 kW range)

    • ORDLFU 20-25-30 (O-ring kit for 15/18/22 kW range)

    • ORDLFU 40-50 (O-ring kit for 30/37 kW range)

    Pump/model cross references customers search by

    • Ebara D-Series examples: DL, ZDLX (DL), DLF, DLFU, DLMFMU (up to 5 HP)

    • Water-jacket designation: DDLFU (“DD” = water jacket)

    • Cross-brand examples shown: HCP 50GF24.5, 50GF23.7 (3.7 kW / 5 HP)

    • Other references seen: F21-0B030NS0000-0, 80DLMKFU, 80DLMFMU

    Disclaimer: Manufacturer names and part numbers are used for reference/cross-reference only and do not imply OEM manufacture.

  • PHYSICAL PROPERTIES

    How to read Ebara D-Series model numbers (for seal sizing)

    Example model: 150 DLFU 6304

    1) Discharge size (first number group)

    150 = discharge size.
    Common sizes:

    • 50 mm (2″) | 80 mm (3″) | 100 mm (4″) | 150 mm (6″) | 200 mm (8″) | 250 mm (10″) | 300 mm (12″)

    2) Model letters (middle group)

    DLFU = the specific D-Series model.
    In the U.S., D-Series models usually start with “D” and often end with “U” (U = U.S. version). You’ll frequently see L, M, and/or F within the code.
    Examples seen in the field: DLFM, DLK, DLMFM, DVF, DBF, DLKWF, DL, DDLF (water jacket), DLFU, DLCMKFU, DLCMFU, and more.

    3) Four-digit performance code (last group)

    6304 helps select the correct mechanical seal and O-ring kit.

    • Position 1: Frequency (e.g., 6 = 60 Hz)

    • Positions 2–3: kW rating (drives seal/O-ring sizing; kW corresponds to HP on U.S. nameplates)

    • Position 4: Voltage code

      • 2 = 208/230 V

      • 4 = 460 V (sometimes shown as 450 V in docs)

      • *5 = 575 V

    kW = HP quick reference (positions 2–3)

    • 1.5 kW = 2 HP

    • 2.2 kW = 3 HP

    • 3.7 kW = 5 HP

    • 5.5 kW = 7.5 HP

    • 7.5 kW = 10 HP

    • 11 kW = 15 HP

    • 15 kW = 20 HP

    • 18 kW = 25 HP

    • 22 kW = 30 HP

    • 30 kW = 40 HP

    • 37 kW = 50 HP

    • 45 kW = 60 HP

    Why this matters

    The kW digits (positions 2–3) and the voltage code (position 4) are key to matching the correct mechanical seal set and O-ring kit for your exact pump build.

    Quick tip:
    Have the full string from your nameplate (e.g., 150DLFU6304) and, if possible, the serial number. Share those with us and we’ll confirm the exact seal and O-ring kit you need—fast. Call us today

Disclaimer: Seal House USA provides aftermarket replacement parts. Any OEM names are used strictly for cross-reference. We are an independent supplier.
